Product Overview
Reflective Fire Barrier Insulation
Insulapack reflective insulation can be used as part of fire-resistant insulation systems in commercial and industrial construction.
The multi-layer reflective structure helps control heat transfer while supporting compliance with fire safety requirements in mechanical and building environments.
Fire Performance and Thermal Efficiency
Insulapack reflective insulation helps improve thermal performance while supporting fire safety requirements in commercial mechanical systems and building assemblies.
The thin insulation profile allows installation in tight mechanical environments where traditional insulation materials may require more space.
Technical Specifications
Key Specifications
Compliance & Testing
Base R-Value:
R-10.6 per inch (material value)
Fire Rating:
ASTM E84 – Class A
Thickness:
5/16 in (8 mm)
Vapor Permeability
0.02 perms (ASTM E96)
Roll Width
48 in (1220 mm)
Smoke Development
Compliant with fire safety standards
Roll Length
125 ft (38 m)
Building Code Compliance
ICC compliant
Reflectivity
Up to 97% radiant heat reflection (ASTM C1371)
Durability
Engineered for transport environments
Why
Why Use This Product
Fire code compliance is non-negotiable on commercial projects. Insulapack fire barrier insulation meets ASTM E84 Class A — Flame Spread Index 25 or below, Smoke Developed Index 450 or below. It installs directly against surfaces in mechanical rooms, plenum spaces, and equipment enclosures without requiring airspace or spacers. For HVAC contractors and mechanical engineers specifying insulation on projects subject to commercial fire code in Canada or the United States, ASTM E84 Class A is the standard that matters.
Application Areas
Where Fire Barrier Insulation Is Used
Designed for building systems where thermal insulation and fire safety performance are required.
Ready to Get Started?
Tell us about your insulation project and receive a customized quote.
Common questions
